Remote MasterMind® Ready: Reduces total cost of ownership by providing a turnkey remote device management solution that easily manages and tracks usage of installed devices
Superior Durability: Incorporates an IP67-rated design that withstands multiple 6 feet drops to concrete and 2,000 1 meter tumbles, resulting in a lower total cost of ownership and decreased downtime for mobile professionals
Shift-PLUS™ Power Management: Enhances productivity by powering real-time wireless and multi-media applications continuously for a full shift, eliminating the need for employees to carry spare batteries or chargers
Adaptus® Imaging Technology 6.0: Enables multi-functional data capture by providing fast scanning of linear and 2D bar codes with excellent motion tolerance, as well as digital image and electronic signature capture
Fast and Reliable Wireless Connectivity: Features leading wireless technology, including a software-definable radio that allows on-the-fly switching between GSM and CDMA networks, as well as 802.11n Wi-Fi, enabling faster and more reliable connections, and lower device provisioning and deployment costs
Optimal Combination of Performance and Usability: Improves ease of use and worker efficiency with a large, outdoor-viewable screen, multiple keypad options, a super fast CPU and smart sensors
Optional Remote MasterMind® Software Package: Extends mobile workforce capabilities and reduces total cost of ownership by providing a turnkey remote device management solution
Optional Service Made Simple™ Service Plans: Offers comprehensive, hassle-free protection on the device investment for up to five years after purchase.
Dimensions |
8.5˝ L x 2.7˝ W (keypad) x 1.5˝ (standard battery)/1.8˝ (extended battery) 215 mm L x 69 mm W (keypad) x 39 mm (standard battery)/45mm (extended battery) |
Weight |
Standard battery – 505g (17.8 oz); Extended battery – 581g (20.5 oz) |
Processor |
Texas Instruments® OMAP3715 1.0GHz processor |
Operating System |
Microsoft® Windows Embedded Handheld 6.5 Professional and Classic |
Memory |
1GB discrete NAND flash x 256 MB RAM |
Display |
Chemically strengthened 3.7˝ transflective active matrix glass display, VGA (480x640), 333 nits |
Touch Panel |
Industrial touch panel with resistive touch and support for finger touch and stylus |
Keypad |
Backlit 55-key alphanumeric, 43-key alpha shifted numeric, 34-key numeric shifted alpha (phone or calculator style) |
Audio |
Speaker, HAC compliant receiver, microphone |
Camera |
3.1 megapixel camera with Automated Camera Control (ACC). Features include automated picture profiles, camera Application Programming Interface (API), cooperational use of camera and imager, and flashlight utility |
I/O Ports |
RS-232/USB 2.0/audio out/charging connector, integrated IrDA port with support for SIR mode |
Storage Expansion |
User accessible Micro SDHC memory card slot. Please check current price guide for available qualified card options |
Battery |
Standard – Li-ion, 3.7V, 3060mAh; Extended – Li-ion, 3.7V, 5000mAh |
Battery Life |
Standard/Extended: 9 hours/15.5 hours (scanning and sending data over WLAN every 9 seconds) Standard/Extended: 8 hours/14.75 hours (scanning and sending data over WWAN every 15 seconds, GPS continuously receiving information) |
Imager/Scanner |
N5600/5603 Standard range (SR), Extended range (ER), and High Density (HD) imagers with high-visibility laser or green LED aimer. All imagers have 25° angle and come equipped with Adaptus 6.0 Imaging Technology |
Decode Capabilities |
Reads standard 1D and 2D symbologies |
WWAN |
GSM (Voice and Data): 3.9G - HSPA+ (800/850/1900/1700/2100 MHz), GSM/GPRS/EDGE (850/900/1800/1900 MHz) Software definable Gobi 3000 (data only): 3.9G – HSPA+/UMTS (800/850/900/1700/1900/2100MHz), GSM/GPRS/ EDGE (850/900/1800/1900MHz), EVDO Rev A - 1xRTT/EVDO (800/1900 MHz); support for dual SIM card |
WLAN |
802.11a/b/g/n, Wi-Fi™ - certified |
WPAN |
Bluetooth® V2.1, support for enhanced data rate 2.0 Mbps & 3.0 Mbps rates class II |
GPS |
Integrated Assisted GPS (A-GPS) with fast position acquisition and low power consumption |
| |
|
|
| |
|
|
| |
|
|
| |
|
|
| |
|
|
| |
|
|
| |
|
|
| |
|
|
| |
|
|
| |
|
|
