Accessories• FlexDock modular docking system• Vehicle dock and holder • Snap-on adaptors • Removable scan handle • Magnetic stripe reader Standard Configuration: • Integrated Camera Option: 5-Megapixel autofocus color camera with LED flash • Accelerometer: Embedded accelerometer enables automatic or application-specific features such as screen rotation or system suspend • IrDA • Integrated Bluetooth® Class II, Version 2.1+EDR Display• 8.9cm (3.5in) Transmissive VGA• 480 x 640 pixels • 65,536 (16 bit RGB) Colors • High-Durability Touch Screen • LED Backlight • Ambient Light Sensor EnvironmentDrop Survival: 2.4 m (8ft.) to concrete per MIL-STD 810G, 1.8m (6 ft) to concrete across operating temperaturerange per MIL-STD 810G 2,000 (1m) tumbles per IEC 60068-2-32 specification Electrostatic Discharge: +/- 15 kV air discharge; +/- 8 kV direct discharge Humidity: Relative Humidity: Non-condensing, 95% Operating Temperature: -20° C to +60° C (-4° F to +140° F)* Transitory Exposures to -30C Recharging Temperature: +5° C to +35° C (41° F to 95° F) Storage Temperature: -30° C to +70° C (-22° F to +158° F) Environmental Protection: Rain & Dust Resistance: IP67 Non-Incendive Version: Products in the 70 Series family with NI certification comply with the following: • Suitable for use in Division 2 locations • Safety: cULus Listing – ISA/ANSI 12.12.01 • Gases: Class I – Groups A, B, C, D • Dusts: Class II – Groups F, G • Fibers and flyings: Class III • * Max Ambient: 50°C T6 Keypad• Numeric with function keys• Alphanumeric • Both keypad options feature hard keycaps with laser-etched legends. Memory and StorageFlash ROM: 1 GB Flash (800 MB available)Memory/Storage Extensions: Customer-accessible micro-SD slot for removable memory cards up to 32 GB RAM Memory: 512 MB RAM (384 MB available) MicroprocessorMulti-Processor Architecture: Texas Instruments® 600MHz or 1 GHz multi-engine processor achitectureOperating SystemMicrosoft Windows Embedded Handheld built on Windows 6.5.3 technology(Getting started information: www.windowsmobile.com/getstarted) Physical CharacteristicsHeight: 5.0 cm (1.98 in)Length: 23.7 cm (9.33 in) Width: 8.0 cm (3.16 in); grip area 6.42cm (2.53 in) Weight: 584 g (19.75 oz) with battery PowerBattery Capacity: 3.7 V, 5200 mAhBattery Type/Supply: Li-Ion, removable, rechargeable SoftwareApplication Development:Intermec Developer Library: www.intermec.com/dev Apps and Components: • VERDEX (Imaging-based data extraction and verification) • eMDI (Mobile Document Imaging) • Intermec Client Pack (Terminal Emulator/Browser) Data Management: • Skynax® Mobile Communications Smart Systems Support: • Device Management: Intermec SmartSystems™ support includes ScanNGo provisioning for use alone or with device management software from Intermec ISVs • Device Health Monitoring: Remote access requires SmartSystem Management option Scan Engine Options• EV12 linear Imager with laser-like aimer; Capable of scanning 1D barcodes at standard range.• EA30 high performance motion-tolerant 2D Imager; white LED illumination; red laser aimer optimized for all lighting conditions; Capable of scanning all common 1D and 2D barcodes; 1D as small as 5 mil; PDF as small as 6.6 mil; Data Matrix as small as 7.5 mil; and standard UPC codes from distances up to 33 cm (13 in). • EX25 near/far 2D Imager; Capable of scanning 1D and 2D barcodes from 15.2 cm to 15.2 m (6 in to 50 ft). |
| |
|
|
| |
|
|
| |
|
|
| |
|
|
| |
|
