Communications
WLAN radio type
802.11a/b/g/n; optional diversity antenna module available
WWAN radio type
Optional UMTS/HSPA+ WAN radio (data only in the Americas1) with GPS receiver (supports AGPS, GLONASS and SBAS)
WPAN (Bluetooth Support)
Integrated Bluetooth® V2.0 + EDR
GPS
Optional GPS/Wi-Fi Diversity Antenna Module (supports AGPS and SBAS)
WLAN
WLAN Data Rates:
802.11a – up to 54 Mbps
802.11b/g – up to 54 Mbps
802.11n @ 2.4 GHz – up to 72.2 Mbps
802.11n @ 5 GHz – up to 72 Mbps
WLAN Security:
WEP (40 or 104 bit); WPA/WPA2 Personal; WPA/ WPA2 Enterprise – EAP-TTLS (PAP, MSCHAP, MSCHAPv2), EAP-TLS, PEAPv0-MSCHAPv2, PEAPv1-EAP-GTC, EAP-FAST, TKIP, AES
Data Capture Options
Scanners
1-D SE965 standard range laser2; 1-D SE1524ER extended range laser3; 1-D SE655 standard range linear imager; 2-D SE4500 imager
NOTE: All scan engines are available factory configured or user installable as either an end cap or slim pod.
Performance Characteristics
Processor (CPU)
Sitara™ AM37x ARM Cortex™ A8 1Ghz processor
Memory
512 MB RAM / 4 GB Flash
Operating system (OS)
Microsoft Windows Embedded CE 6.0, Windows Embedded Handheld 6.5
Applications
Bundled Applications: Internet Explorer®; Wordpad®; ActiveSync®; Microsoft Office (WEHH 6.5 only)
Additional Software: Kiosk; MobiControl; Total Recall/TweakIt/Dr. Debug; A.R.C.; Windows® Mobile Device Center
Terminal Emulation: TekTerm; Wavelink TE
Physical Characteristics
Camera
Optional color, 8 MP, autofocus, 4X digital zoom, Bright
LED
flash, video capable
Dimensions (HxWxD)
Long: 8.78" x 2.95"/3.94" x 1.22"/1.65" (223 mm x 75/100 mm x 31/42 mm)
Short: 7.87" x 2.95"/3.94" x 1.22"/1.65" (200 mm x 75/100 mm x 31/42 mm)
Weight
Long: 18.6 oz / 526 g
Short: 16.2 oz / 461 g
Keypad options
Alpha Numeric (long models)
QWERTY or Numeric (short models)
High reliability keypad ultra-white backlight
Display type
3.7 in VGA/QVGA (640 x 480), transflective color; touch display; Sunlight visibility with 240 cd/m² brightness
Voice, Speech and Audio
Voice over WWAN1; Push-to-Talk – Voice over Wi-Fi (VoWiFi) capable1; optional headset adapter module to support speech picking applications; integrated microphone and receiver with high volume 86dBA beeper (95dBA beeper with extended range laser)
Power
Battery
PowerPrecision Lithium Ion batteries
Two options: High capacity 4400 mAh or standard capacity 2760 mAh
RFID
Module options
LF Module
Frequency: 125 kHz
Protocols supported: EM 4x02; EM 4x05; EM 4x50; EM 4200; Q5; Hitag 1 & 2; Hitag S
UHF Module* Frequency: 868 MHz or 915 MHzProtocols supported: EPC Class 1 Gen 2;ISO 18000-6C
HF Module Frequency: 13.56 MHz Protocols supported: ISO14443 type A, B and C, ISO 15693; NFC “Reader to Tag” Mode; fullMifare supportData encryption: 2 SAM slots; ID1 SAM format;Class A, B and C
User Environment
Environmental sealing
IP65
Operating temperature
-4°F to 122°F (-20°C to +50°C)
Storage temperature
-40°F to 140°F (-40°C to +60°C)
Humidity
5%-95% non-condensing
Drop specification
Multiple 5 ft. (1.5 m), 26 drops to polished concrete (powered with options and accessories); multiple 6 ft. (1.8 m) drops to polished concrete
Electrostatic discharge (ESD)
+/- 8kV contact, +/- 15kV air discharge
